Schneider A9D11210 – Acti9 iDPN Miniature Circuit Breaker
Product Overview
Series: Acti9 iDPN
Type: Single Pole + Neutral MCB
Application:
– Residential electrical distribution
– Light commercial circuits
– Final circuit protection
Key Specifications
Rated Current: 10A
Breaking Capacity: 6kA
Tripping Curve: C
Rated Voltage: 230/400V AC
Poles: 1P+N
Features
Compact 2-module width
Double break contact system
Terminal accepts up to 25mm² conductors
VDE, CE, CCC certified
Ordering Information
Schneider Part No.: A9D11210
Compatible Accessories
End Cap: A9ZQC162
DIN Rail: A9ZQA102
