Trina Solar TSM-DEG19RC.20 Solar Panel Technical Specifications
Electrical Characteristics
– Power Output (Pmax): 605W – 635W
– Module Efficiency: Up to 22.3%
– Cell Technology: N-Type i-TOPCon Monocrystalline Silicon
– Number of Cells: 132 Half-Cut Cells (210mm size)
– Open-Circuit Voltage (Voc): 49.8V – 51.2V
– Max Power Voltage (Vmp): 41.3V – 42.7V
– Short-Circuit Current (Isc): 14.8A – 15.4A
– Max System Voltage: 1500V DC
– Temperature Coefficients:
– Pmax: -0.29%/°C
– Voc: -0.24%/°C
– Isc: +0.04%/°C
Physical Specifications
– Dimensions (L × W × H): 2384mm × 1303mm × 35mm
– Weight: Approx. 35.2kg
– Junction Box: IP68 rated
– Connectors: MC4 EVO2
Environmental Durability
– Operating Temperature Range: -40°C to +85°C
– Bifacial Design: Dual 2.0mm tempered glass
– Mechanical Load Capacity: 5400Pa (wind/snow load)
– Hail Resistance: Passes IEC 61215 (35mm hail at 27m/s)
– Fire Rating: Class A (IEC 61730 compliant)
– Corrosion Resistance: Salt mist, ammonia, and dust resistant
Warranty & Reliability
– Product Warranty: 12 years
– Power Output Warranty:
– Years 1-10: ≤ 1% annual degradation
– Years 11-30: ≤ 0.45% annual degradation
– End of 30 Years: ≥ 85.5% of initial power output
